500 Channels LED Display Digital Ultrasonic Flaw Detector

Name: 500 Channels LED Display Digital Ultrasonic Flaw Detector
Brand: HCATM
Price: 1 USD

Quality 500 Channels LED Display Digital Ultrasonic Flaw Detector for sale

Brand Name : HCATM

Model Number : HU9103

Certification : CE，RoHS

Place of Origin : Xi'an

MOQ : 1PCS

Brand : HCATM

Channels : 500

Frequency Range (MHz) : 0.5 ~20MHz

Material velocity (m/s) : 1000 ~9999m/s

Vertical linearity error : ≤3%

Horizontal linearity error : ≤0.1%

Contact Now

LED Display HU9103 Digital Ultrasonic Flaw Detector

HU9103

Digital Ultrasonic Flaw Detector

The digital ultrasonic flaw detector is a portable industrial non-destructive flaw detection instrument that can quickly, conveniently, damage-free and accurately detect, locate, evaluate and diagnose various defects (cracks, looseness, pores, inclusions, etc.) inside the workpiece.

500 Channels LED Display Digital Ultrasonic Flaw Detector

Product Parameter

Measuring Range (mm)	0 ~15000mm
Channels	500
Frequency Range (MHz)	0.5 ~20MHz
Material velocity (m/s)	1000 ~9999m/s
Vertical linearity error	≤3%
Horizontal linearity error	≤0.1%
Sensitivity leavings	≥62dB
Dynamic range	≥32dB
Resolving power	≥36dB
Gain (dB)	0 ~110dB
Reject	0~80%
Pulse Displacement (μs)	-20 ~+3400
Zero (μs)	0.0 ~99.99
Operating Temperature (℃)	-20~70
HWD(mm)	24515555
Weight (kg)	1.18(with battery)

500 Channels LED Display Digital Ultrasonic Flaw Detector

Product Tags:

Digital Ultrasonic Flaw Detector

LED Display Ultrasonic Flaw Detector

500 Channels Ultrasonic Flaw Detector

500 Channels LED Display Digital Ultrasonic Flaw Detector Images
